MANIFOLD INLET: OK FV ACTUATOR 8000 PSI RETURN LINE MIL-DTL-25579 / NAS 1501 SYSTEM STATUS: NOMINAL
Thermal Management · Category 02

Heat Exchangers & Cold Plates

High-performance brazed aluminum heat exchangers, liquid-cooled cold plates, and oil coolers designed for electronics thermal management, engine cooling, and environmental control systems in demanding aerospace applications.

Core MaterialBrazed Aluminum 3003/4343 Alloy
Cold Plate MaterialAl 6061-T6, Al 3003, Cu (per requirement)
Thermal PerformanceUp to 50 kW heat rejection per unit
Operating PressureUp to 3,000 PSI (HEx), 1,500 PSI (cold plate)
Temperature Range-54°C to +200°C continuous
Coolant MediaMIL-PRF-5606, PAO, Water-glycol, Skydrol
Test StandardsMIL-STD-810H, DO-160G, RTCA/DO-178C

Deployed for thermal management on:

Radar Transmitters EW Systems Avionics Bays Engine Gear Boxes Fuel System Cooling Power Electronics LRU Chassis Cooling
🌡️
Thermal Management
Heat Exchangers & Cold Plates
Up to 50 kW Heat Rejection Capability
HEAT EXCHANGER CORE COOLANT IN (35°C) COOLANT OUT (78°C) HOT SIDE: 50 kW LOAD BRAZED ALUMINUM BAHX
Tactical Electronics · Category 03

Tactical Communication Systems

SATCOM terminal units and tactical data link modems engineered for secure, high-bandwidth beyond-line-of-sight communication. Designed for platform integration into fixed-wing aircraft, rotary, and ground vehicles.

SATCOM BandsKu-band (10.7–18 GHz), Ka-band (26.5–40 GHz)
Data Link StandardLink 11 / Link 16 / Link 22 compatible
Data RateUp to 274 Mbps downstream
EIRPUp to 45 dBW (platform-dependent)
EncryptionAES-256, HAIPE compliant
InterfacesMIL-STD-1553B, ARINC 429, GbE
EMI StandardsMIL-STD-461G, MIL-STD-464C

Integrated and operational on:

Maritime Patrol Aircraft AEW&C Platforms UAV Ground Stations Mobile Command Posts Naval Frigates Armored Vehicles
📡
Tactical Comm
SATCOM & Data Link Systems
AES-256 Encrypted · Link 16 Ready
SAT TERMINAL UNIT SECURE LINK (AES-256) AIRCRAFT GND STN BANDWIDTH: 274 Mbps | FREQUENCY: Ku/Ka BAND MIL-STD-461G / MIL-STD-1553B COMPLIANT
Navigation Systems · Category 04

NavIC Receiver Module

Indigenous dual-frequency NavIC (L5+S band) receiver designed for precision navigation in GPS-denied or GPS-degraded environments. Certified for airborne and land-based military applications with sub-meter accuracy.

Signal BandsNavIC L5 (1176.45 MHz) + S-band (2492.028 MHz)
ConstellationNavIC + GPS + GLONASS + Galileo (multi-GNSS)
Position Accuracy<5m (open sky), <2m (SBAS augmented)
Velocity Accuracy0.1 m/s RMS
Time-to-First-Fix<60 sec cold start, <2 sec hot start
Operating Temp-40°C to +85°C (MIL-STD-810H Cat A1)
InterfaceRS-422/485, MIL-STD-1553B, ARINC 429, NMEA 0183

Qualified for use in:

LCA Tejas Navigation UAV Autopilot Ballistic Guidance Artillery Fire Control Ship Navigation Personal Role Radio Weapon Systems
🛰️
NavIC Receiver
L5 + S Band Dual Frequency
Sub-5m Accuracy · MIL-GRADE
NavIC GPS GLONASS NavIC RECEIVER L5 + S DUAL PROCESSOR ACCURACY: <0.85m NOMINAL
Tactical Software · Category 05

AI/ML Software Suite

Advanced neural network applications and generative language models engineered for edge intelligence, mission autonomy, and tactical command support.

System CapabilityMulti-class real-time military object detection
Algorithm BackboneOptimized RT-DETR / YOLOv8 edge network
Detection ClassesInfantry, armored vehicles, UAVs, artillery, installations
Inference Latency< 8ms on NVIDIA Jetson Orin Industrial
Accuracy Rating98.2% mAP50-95 under fog, rain, and low-light conditions
Sensor InputsEO/IR, SWIR, thermal LWIR, and multispectral video feeds

Engineered for autonomous reconnaissance, border monitoring, and real-time situational awareness platforms.

System CapabilityLock-on tracking and fire-control target detection
Tracking CoreDeepSORT with customized tactical Kalman filtering
Target ClassFighter aircraft, rotary-wing, missiles, hypersonic targets
Telemetry ProcessingRange, azimuth, elevation, relative velocity vector
Parallel TrackingLocks and tracks up to 64 active military targets simultaneously
Electronic ProtectionECCM filters resisting thermal flares and decoy chaffs

Designed for air defense units, fire-control systems, and anti-UAV kinetic tracking platforms.

System CapabilityAir-gapped tactical operational generative AI assistant
Language CoreFine-tuned secure Llama-3 8B parameter model
Hosting Mode100% Offline, on-premise hardware, zero external leakage
Primary RolesSOP retrieval, battle-staff checklists, log summaries, tactical planning
Response Speed> 45 tokens per second (first token in < 0.8 seconds)
Interfacing ProtocolsEncrypted offline voice-to-text and secure text terminal

Engineered for underground command bunkers, naval vessels, and remote tactical operations centers where connectivity is zero.

Object Detection AI
Edge Vision AI
Real-Time Object Detection
Thermal & EO Multi-Class Classification
Target Detection AI
Targeting AI
Lock-On Target Tracking
Precision Telemetry & Path Projection
Generative AI
Secure LLM
Tactical Generative AI
Air-Gapped Decision Support Assistant

Certifications & Accreditations

Adhering to the highest global standards for aerospace engineering and manufacturing quality.

✈️
AS9100 Rev D
SAE International · IAQG
Valid through Dec 2026
🏅
ISO 9001:2015
Bureau Veritas · QMS
Valid through Mar 2027
⭐
CMMI Level 3
CMMI Institute · DEV v2.0
Appraised 2024
🔐
ISO 27001:2022
TÜV SÜD · ISMS
Valid through Sep 2026
🔬
NADCAP
PRI · Non-Destructive Testing
Valid through Jun 2026
